AS 1200 AC1 Battery spray blower (CAS with battery pack, with charger)

Article number: 12118201 / EAN: 7611034014333
AS 1200 AC1
  • Birchmeier Akku-Sprühgebläse mit geringer Abdrift im Weinbau

New: 50% more efficient. Spray effectively and efficiently thanks to air support.

A new dimension to plant protection: Spraying with pressure-controlled liquid supply into the air stream. A large spraying range can be achieved with pre-spraying and a variable air stream. A minimum loss of spray solution and a long reach is the result. The air stream also causes the targeted leaves to move, providing optimum wetting and penetration of foliage and shrubbery. The AS 1200, powered by an additional battery, is combined with a sprayer from the «Accu-Power» line. The spray blower is extremely powerful, easy to operate and impressively quiet. Thus, the AS 1200 is much more than a ordinary mist blower.



Powerful and quiet performance

  • Up to 6 hours of rechargeable battery power
  • Adjustable air speeds up to 213 ft/s
  • Additional power level
  • Spray distance up to 42 ft
  • Low noise emission
  • High energy efficiency



Unlimited uses

Testimonials

  • Viticulture
  • Fruit growing
  • Gardening and landscaping
  • Ornamental plant cultivation
  • Nurseries
  • Vegetable growing
  • Mosquito control



Only in combination with the Birchmeier «Accu-Power» line (REB 15, REC 15, REX 15, A 50, A 75, A 130, BM 1035)



NEW with CAS: One battery, many solutions

  • CAS* - Unlimited combinations
  • Cross-manufacturer compatibility: 300 devices - 36 brands - 1 battery
  • Different battery packs obtainable (up to 10 Ah)
  • Charge level is displayed by LED lights
  • 3 year guarantee with registration under www.birchmeier.com/3y

* CAS (Cordless Alliance System is a cross-manufacturer battery pack system of leading power tool brands)

 «Accu-Power» Line

www.cordless-alliance-system.com

Read more

Technical data
Chemical resistanceFor use with the most plant protection products.Not suitable for formic acid, acetic acids, sodium / potassium hydroxides. In addition stainless steel units: no hydrochlonic acid, nitric acid, sulfuric acid or hydrofluoric acid, ammonia, peroxides and other corrosive media.Not suitable for mineral oil based and vegetable oils, hypochlorites, limonenes, terpenes.Not suitable for non-polar solvents, ketones, peroxides, chlorine, acids and alkalines.
ApplicationPesticide
Water
Biological agents
Plant protection
Herbicides
Disinfection
Form of applicationLiquid
Max. working pressure (bar)10
Nozzle typeAnti drift hollow cone AITXA 8002 VK
Anti drift hollow cone AITXA 8003 VK
Anti drift hollow cone AITXA 8001 VK
Spray patternHollow cone nozzle (for smaller shrubs and plants)
Nozzles materialPlastic / Ceramics
Material Device/containerPlastic
Material Fittings
Fitting connectorsscrew fitting
Stress classVery heavy duty
Length (mm)464
Width (mm)160
Height (mm)304
Weight (kg)3.5
Device typeBattery spray blower
Special functionBattery unit 2x 18 VSuitable for disinfection
Nozzles data
Anti drift hollow cone AITXA 8002 VKAnti drift hollow cone AITXA 8002 VKTechnical parametersSpray patternHollow cone nozzle (for smaller shrubs and plants)Pressure range15 – 145 psiFlow rate gal/minpsiDroplet size depending on pressure
Pressure (psi)152944587387102116131145
Spraying
To the nozzle
Anti drift hollow cone AITXA 8003 VKAnti drift hollow cone AITXA 8003 VKTechnical parametersSpray patternHollow cone nozzle (for smaller shrubs and plants)Pressure range15 – 145 psiFlow rate gal/minpsiDroplet size depending on pressure
Pressure (psi)152944587387102116131145
Spraying
To the nozzle
Anti drift hollow cone nozzle AITXA 8001 VKAnti drift hollow cone nozzle AITXA 8001 VKTechnical parametersSpray patternHollow cone nozzle (for smaller shrubs and plants)Pressure range15 – 145 psiFlow rate gal/minpsiDroplet size depending on pressure
Pressure (psi)152944587387102116131145
Spraying
To the nozzle
Special nozzle NF 125, G1/4"iSpecial nozzle NF 125, G1/4Technical parametersSpray patternFine hollow cone nozzle (especially suitable for the disinfection)Pressure range15 – 145 psiFlow rate gal/minpsiDroplet size depending on pressure
Pressure (psi)152944587387102116131145
Spraying
To the nozzle
Videos
DownloadsTreatment Japanese beetle Treatment Japanese beetle Leaflet AS 1200 GardenLeaflet AS 1200 PCOLeaflet AS 1200 ConstructionLeaflet AS 1200 Chicken coopDisinfect with BirchmeierDisinfection compatibility listAS 1200 Testimonial - Box trees, Lampart Gartenbau AS 1200 Testimonial - Rose protection, Moacir KunrathAS 1200 Testimonial - Box trees and rose protection, Peter HagmannAS 1200 Testimonial - Garden keeping roses box trees high fruit treesAS 1200 Testimonial - Garden keeping for private homes roses box trees chestnut treesAS 1200 Testimonial - Plants and herbsAS 1200 Testimonial - Espaliers, Toon CoolsAS 1200 Testimonial - Garden maintenance and boxwood, Peter CoppensAS 1200 Testimonial - Viniculture, Franz SteigerAS 1200 Testimonial - Viniculture, private userAS 1200 Testimonial Viticulture, Eva-Maria Weber AS 1200 Testimonial - Viticulture, Annebergsgård VarbergAS 1200 Testimonial - High fruit trees, Franz PeterhansAS 1200 Testimonial - Crop production, Slottsträdgården UlriksdalåAS 1200 Testimonial - Crop production, Frank SannmannAS 1200 Testimonial - Crop production, Kai BurmesterAS 1200 Testimonial - Crop production, Robin.pdfAS 1200 Testimonial - Poultry farmsAS 1200 Testimonial - PCO, Dario CattaneoAS 1200 Testimonial - PCO, Jan SampermansAS 1200 Testimonial - PCO, Chris BuckalooAS 1200 Testimonial - PCO, Dan SmithAS 1200 Testimonial - PCO, Marina S. KaremaGeneral catalogue AS 1200 TestimonialsCombination AS 1200 with battery backpack sprayersCombination AS 1200 with wheelbarrow sprayers
Safety regulationsSafety regulations
Spare parts and error codeSpare parts and error code AS 1200 AC1
